DPS310 Sensor IC XENSIV Digital Barometric Air Pressure Sensor For Portable Devices

DPS310 Sensor IC XENSIV Digital Barometric Air Pressure Sensor For Portable Devices​

Product Description Of DPS310

DPS310 is a miniaturized Digital Barometric Air Pressure Sensor with a high accuracy and a low current consumption, capable of measuring both pressure and temperature. The pressure sensor element is based on a capacitive sensing principle which guarantees high precision during temperature changes. The small package makes the DPS310 ideal for mobile applications and wearable devices.

Specification Of DPS310

Features Of DPS310

Operation range: Pressure: 300 –1200 hPa. Temperature: -40 – 85 °C.
Pressure sensor precision: ± 0.002 hPa (or ±0.02 m) (high precision mode).
Relative accuracy: ± 0.06 hPa (or ±0.5 m)
Absolute accuracy: ± 1 hPa (or ±8 m)
Temperature accuracy: ± 0.5°C.
Pressure temperature sensitivity: 0.5Pa/K
Measurement time: Typical: 27.6 ms for standard mode (16x). Minimum: 3.6 ms for low precision mode.
Average current consumption: 1.7 µA for Pressure Measurement, 1.5uA for Temperature measurement @1Hz sampling rate, Standby: 0.5 µA.
Supply voltage: VDDIO: 1.2 – 3.6 V, VDD: 1.7 – 3.6 V.
Operating modes: Command (manual), Background (automatic), and Standby.
Calibration: Individually calibrated with coefficients for measurement correction.
FIFO: Stores up to 32 pressure or temperature measurements.
Interface: I2C and SPI (both with optional interrupt)
Package dimensions: 8-pin LGA, 2.0 mm x 2.5 mm x 1.0 mm.

Applications Of DPS310
Indoor Navigation (floor detection e.g. in shopping malls and parking garages)
Health and Sports (accurate elevation gain and vertical speed)
Outdoor Navigation (GPS start-up time and accuracy improvement, dead-reckoning e.g. in tunnels)
Weather Station('Micro-weather' and local forecasts)
HDD drivers, (leak rate detection in hard disk drives)
Drones (flight stability and height control)
